Small Resistance Steel Bundy Tube Bao Steel Strip For Transmission Oil Cooler

Small Resistance Steel Bundy Tube Bao Steel Strip For Transmission Oil Cooler

    • Small Resistance Steel Bundy Tube Bao Steel Strip For Transmission Oil Cooler
    • Small Resistance Steel Bundy Tube Bao Steel Strip For Transmission Oil Cooler
    • Small Resistance Steel Bundy Tube Bao Steel Strip For Transmission Oil Cooler
  • Small Resistance Steel Bundy Tube Bao Steel Strip For Transmission Oil Cooler

    Product Details:

    Place of Origin: Jiangsu,China
    Brand Name: Hongbao
    Certification: ISO,TUV
    Model Number: Hongbao-BT01

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 ton
    Price: Negotiable
    Packaging Details: Seaworthy Coil Bundle Packing.
    Delivery Time: Within 50 days
    Supply Ability: 1500MT per year
    Contact Now
    Detailed Product Description
    Material:: SPCC-KL, Low Carbon Steel Thickness:: 0.5-1.0mm
    OD:: 4-10mm Processing:: Welded
    Sample: Free Sample Port: Shanghai Port

    Bundy Tube 4.76*0.7 Signle Coating Coiled Steel Bundy Tube Refrigerator Condenser Application



    Description:

    1. Main use: widely used in evaporators, refrigerators, automobiles and heaters
    2. Features: high intensity, good plasticity, and small resistance
    3. Standard: ASTMA254-94
    4. Materials: materials can be altered according to customers' requirements
    5. Size: 4.7*0.7mm, 6.35*0.7mm,
    6. Type: Zinc coating outer side, Cu coating outer side, Cu coating both sides
    7. Packing: packed with iron pallet



    Outer

    diameter

    wall thickness tolerance (mm)

    wall thickness

    (mm)

    weight

    (g/m)

    weight

    zinc

    (g/m)

    weight

    PVF

    (g/m)

    Resistance

    to pressure

    length (m/ ton)
    4.76(3/16) ±0.05 0.7 70 71 72 88 13889
    6 ±0.05 0.7 91 92 93 70 10753
    6.35(1/4) ±0.05 0.7 97 98 99 64 10000
    8(5/16) ±0.05 0.7 125 127 128 51 7813
    10 ±0.05 0.7 160 162 163 41 6135
    12 ±0.05 0.7 194 196 198 34 5051
    8 ±0.05 1.0 172 174 175 72 5714
    10 ±0.10 1.0 220 222 223 58 4484
    12 ±0.10 1.0 270 272 274 48 3650



    Mechnical

    property



    Tensile Strength≥ 290 Mpa



    Yield Strength ≥180Mpa

    Elongation≥25%

    Inside Surface Cleaniess≤ 0.16g/m2





















    P







    Packing :

    Coils or Bundles ,then in pallets or wooden boxes

    Water-proof packing, using plastic film for inner package , and plastic woven bag for

    outside package



    Delivery Time:
    Within 45 days
    Other situation can be followed the negotiation by two parties.
