EN10305-2 34MnB5 Welded Steel Tube with Cold Drawn Technique and 285–360MPa Yield Strength for Hollow Stabilizer Bar

Name: EN10305-2 34MnB5 Welded Steel Tube with Cold Drawn Technique and 285–360MPa Yield Strength for Hollow Stabilizer Bar
Brand: Jiangsu Hongbao Group Co., Ltd.
SKU: HBPST-1
Price: 22.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: HONGBAO

Certification: TS16949, ISO9001, OHSAS18001 etc.

Model Number: HBPST-1

Payment & Shipping Terms

Minimum Order Quantity: 1 ton

Price: Negotiable

Packaging Details: Seaworthy Wooden box, customized Packing

Delivery Time: 30-45 days

Payment Terms: L/C,T/T

Supply Ability: 60000 MT per year

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                welded steel pipe, welding round tubing


Material:	34MnB5	Standard:	EN10305-2
Shape:	Round	Technique:	Cold Drawn
Origin::	Jiangsu,China	Certificate::	TS16949, DNV, PED

Material:	34MnB5
Standard:	EN10305-2
Shape:	Round
Technique:	Cold Drawn
Origin::	Jiangsu,China
Certificate::	TS16949, DNV, PED

EN10305-2 34MnB5 Welded Steel Tube with Cold Drawn Technique and 285–360MPa Yield Strength for Hollow Stabilizer Bar

EN10305-2 34MnB5 Φ28 x 5 Welded Steel Tube, Thin Wall Steel Tubing For Hollow Stabilizer Bar

Product Overview

The 34MnB5 welded steel tube, conforming to EN10305-2 standards, is specifically engineered for hollow stabilizer bar production. This alloy combines manganese, boron, and carbon to deliver exceptional strength, hardness, and weldability. Designed for optimal performance under dynamic stress conditions, it is ideal for stabilizer bar applications where rigidity and durability are paramount.

Manufacturing Process

Hollow Stabilizer Bar Tube is produced by drawing ERW (electric resistance welded tube). During this process, sizing (wall thickness, inside and outside diameter), weld integrity, and surface finish are closely controlled to produce tube of the required size and mechanical property characteristics.

Technical Specifications

Material	34MnB5
Other Material Available	26MnB5
OD	10-50mm
WT	1.5-8mm
Standard	EN10305-2
Technique	Cold Drawn

Typical Specification

Φ28*5	285～360Mpa
Yield Strength	235-300Mpa

Application

Hollow Stabilizer

Delivery Condition

+C: No heat treatment after the final cold drawing process
+N: After the final cold drawing operation, the tubes are normalized in a controlled atmosphere

Production Capacity

No.	Welding Specification	Unit Speed (m/min)	Working Time (Hour)	Capacity (Ton)	Ratio of Total Output
1	Φ34×6	18	1211	11200	56%
2	Φ28×5.2	20	1522	-	-
3	Φ38×4.5	28	883	5500	27.5%
4	Φ50.8×2.3	60	114	1130	5.6%
5	Φ55×3	50	190	2170	10.8%
Total	-	-	3920	20000	100%

Quality Testing

Tubes are controlled 100% by Ultrasonic test and Eddy Current Test. We maintain our own laboratory to ensure quality control of both materials and finished products.
