Product Details
Place of Origin: Jiangsu, China
Brand Name: HONGBAO
Certification: TS16949, ISO9001, OHSAS18001 etc.
Model Number: HBPST-1
Payment & Shipping Terms
Minimum Order Quantity: 1 ton
Price: Negotiable
Packaging Details: Seaworthy Wooden box, customized Packing
Delivery Time: 30-45 Days
Payment Terms: L/C, T/T
Supply Ability: 60000 MT per Year
Material: |
E355 Welded Carbon Steel Tube |
Technique: |
Cold Drawn |
OD: |
10-50mm |
WT: |
1.5-8mm |
Certificate: |
TS16949, DNV, PED, ISO |
Shape: |
Round |
Material: |
E355 Welded Carbon Steel Tube |
Technique: |
Cold Drawn |
OD: |
10-50mm |
WT: |
1.5-8mm |
Certificate: |
TS16949, DNV, PED, ISO |
Shape: |
Round |
EN10305-2 E355 DOM Pipe Cold Drawn Welded Steel Tube
Description:
DOM pipe, manufactured with high-quality steel alloys, undergoes a precise cold drawing process to ensure tight tolerances and smooth seams. Our cold drawn welded steel tube DOM pipes are ideal for automotive, industrial and construction applications, offering exceptional strength, corrosion resistance and durability.
Chemical Compositions:
| Steel Number | Quality Level | Thickness/mm | Deoxidize Method | C(%)≤ | Si(%)≤ | Mn(%)≤ | P(%)≤ | S(%)≤ |
| E235(Fe360) |
A B
C D |
≤16 ＞16-25 ≤40 ＞40
|
N - - E NE NE GF |
0.22 0.17 0.20 0.17 0.20 0.17 0.17 |
- 0.40 0.40 0.40 0.40 0.40 0.40 |
- 1.40 1.40 1.40 1.40 1.40 1.40 |
0.050 0.045 0.045 0.045 0.045 0.040 0.035 |
0.050 0.045 0.045 0.045 0.045 0.040 0.035 |
| E355(Fe510) |
C D |
≤30 ＞30 ≤30 ＞30 |
NE NE GF GF |
0.20 0.22 0.20 0.22 |
0.55 0.55 0.55 0.55 |
1.60 1.60 1.60 1.60 |
0.040 0.040 0.035 0.035 |
0.040 0.040 0.035 0.035 |
Main Data:
Material: E355
Other material aviable: E235
Standard: EN10305-2
Technique: Cold Drawn
Od:6-80
Wt:0.5-10
DOM Tube-The cold rolled welded tube is produced by drawing ERW (electric resistance welded tube).During this process the sizing (wall thickness, inside and outside diameter), as well as weld integrity and surface finish is closely controlled to produce tube of the required size and mechanical property characteristics.
Advantage (compare with seamless cold drawn tube):
1.Better shape
2.Improved quality surface
3.Tight Excentricity and wall thickness tolerances (the eccentric
4.Tube more safety
5.Good toughness at low temperature
6.USA Market: 90% of the cylinder in the USA market are produced with welded tubes
7.Cost fix Lengths More Cheaper
Application:
Producing camshaft
Delivery Condition:
+C No heat treatment after the final cold drawing process
