Product Details
Place of Origin: China
Brand Name: Hongbao
Certification: ISO9001, OHSAS18001,TS16949 etc
Payment & Shipping Terms
Minimum Order Quantity: 3 tons
Price: Negotiable
Delivery Time: 25 days
Supply Ability: 20000 ton/year
Material: |
100Cr6, SKF3, GCr15, SKF3S |
Standard: |
GB/T18254, YB/T4146 |
Keywords: |
Bearing Steel Tube |
Delivery Condition: |
Annealing |
OD: |
10-160mm |
WT: |
3.5-25mm |
Material: |
100Cr6, SKF3, GCr15, SKF3S |
Standard: |
GB/T18254, YB/T4146 |
Keywords: |
Bearing Steel Tube |
Delivery Condition: |
Annealing |
OD: |
10-160mm |
WT: |
3.5-25mm |
Gcr15 Precision Cold Drawn Seamless Bearing Steel Tube for Auto Parts
|
Material:
|
GCr15 |
|
Standard:
|
GB/T18254, YB/T4146 |
|
Delivery Condition:
|
+A |
| Application: | High Precision Steel Bearing Tube is Widely Used in Bearing Industry and Automotive Parts |
|
Process:
|
Piercing,Cold Drawing, Spheroidizing Annealing, Annealing etc. |
Bearing steel pipe is the seamless steel tube for hot rolling or cold rolling (cold drawing) for the manufacture of ordinary rolling bearing ring. The outer diameter of the steel tube is 25-180 mm, and the wall thickness is 3.5-20mm, which is divided into ordinary precision and high precision. Bearing steel is used for making ball bearings, roller bearings and bearing rings. Bearing is under great pressure and friction, so the bearing steel is required to have high and uniform hardness and wear resistance, and high elastic limit. On the uniformity of the chemical composition of bearing steel, the content and distribution of non-metallic inclusions are very demanding, the distribution of the carbide, etc, are all steel production in one of the most demanding steel grade.
1. Chemical Component
| C % | Mn % | Si % | P % | C % | Cr % |
| 0.95-1.05 | :0.20-0.40 | 0.15-0.35 | 0.020 | 0.027 | 1.30-1.65 |
2. Quality Control:
1. Selection of raw materials: Choose the best raw material.
2. Advanced detection equipment:The turbine detector, Ultrasonic flaw detection & Infrared detection apparatus.
3. Test report with 3rd party.
3. Trade Information
| Trade Term | FOB, EXW, CIF |
| MOQ | 10000KG |
| Payment | 30% TT in advance, balance before shippment or B/L at sight. |
| Sample | Free sample but postage is required. |
| Delivery Time | 15-60 days |
| Package | Standary export package or as requirement |
| Other service | As customer requirement |
