Bending Double Wall Tube 6 * 1 mm Galvanized Coated For Freezer Compressor
| Place of Origin | Jiangsu,China |
|---|---|
| Brand Name | Hongbao |
| Certification | TUV,LR |
| Model Number | Hongbao-BT01 |
| Minimum Order Quantity | 1 ton |
| Price | Negotiable |
| Packaging Details | Seaworthy Coil Bundle Packing. |
| Delivery Time | Within 50 days |
| Supply Ability | 1500MT per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | SPCC-KL, Low Carbon Steel | Shape | Round Coil |
|---|---|---|---|
| OD | 4-10mm | Processing | Welded |
| Sample | Free Sample | Port | Shanghai Port |
| High Light | erw galvanized pipe,coated steel tube |
||
Product Description
6*1mm Double Wall Bundy Tubes Galvanized Coated Tube For Refrigerator Freezer Compressor
Description:
1. Material:bao steel strip,low carbon
2. Main use:widely used in refrigeration,compressor,condenser,freezer,air conditioning etc
3. Outer diameter:5-12mm
4. Wall Thickness:0.5-1.0mm
5. Standard:ASTMA-254
6. Certification:also passed ISO9001quality attestation system and ISO14001 Certificate of Environment Management System
7. Surface treatment:Galvanized, Copper coated
8. Feature:soft and easy to bend
9. Tensile strength:more than 290Mpa
10. Yield strength:more than 180Mpa
11. Elongation:more than 25%
12. Place of origin:jiangsu province,China
13. Port of loading:shanghai,china
14. Package:plastic cloth coil,wooden box,iron pallet etc
15. Delivery:Within 45 Days
Specification:
| specification | dimensional tolerance | Mechanical properties | |||
| Diameter tolerance | Wall thickness tolerance | tensile strength | yield strength | elongation | |
| bundy tube 6*1mm | ±0.08 | ±0.08 | ≥290Mpa | ≥180Mpa | ≥25% |
Single-Wall Tubes
Main Characteristics: Excellent mechanical property, extremely good inside cleanness and nice foundation for late process. The tube can be provided in coils or cut to length and mainly for refrigeration industry and auto industry. It is an ideal material for all kinds of fluid and gas transmission tubes. All kinds of surface treatments are available according to the need from the customers.
Double-Wall Tubes
Main Characteristics: Fine inside cleanness, high strength, nice elongation, good foundation for late process , anti leakage, anti high pressure explosion, excellent anti corrosion power after surface treatment. It is an ideal material for tubes of condensation , evaporation and autos.
The tube can be provided in coils or cut to length -- plain/oil coated bundy tube, galvanized bundy tube, copper coated bundy tube, PVF coated bundy tube, etc.
