Hydraulic Bright Annealed Tube , High Stability E355 Welded Steel Pipe
| Place of Origin | Jiangsu, China |
|---|---|
| Brand Name | Hongbao |
| Certification | TS16949,DNV,PED,ISO,TUV,LR |
| Model Number | HBPST-1 |
| Minimum Order Quantity | 1 ton |
| Price | Negotiable |
| Packaging Details | seaworthy plywooden case packing. |
| Delivery Time | Within 50 days if production |
| Supply Ability | 30000MT per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Keywords | Bright Annealed Tube | OD | 6-120mm |
|---|---|---|---|
| Thickness | 0.5-15mm | Processing | Cold Drawn, Cold Rolled |
| Sample | Free Sample | Material | E355 |
| High Light | hydraulic cylinder pipe,st52 honed tube |
||
Product Description
EN10305-1E235 E355 Steel Tube Welded Hydraulic Bright Annealed Steel Tube
Description:
1. Product Name: EN10305-1E235 E355 Steel Tube Welded Hydraulic Bright Annealed Steel Tube
2. Size Range: OD: 6-88mm, WT: 1-15mm, Length: 5.8m/6m, maximal 11.8m
3. Stable Quality with Comeptitive Price
4. +N(Normalized) Heat Treatment, Surface is clean and smooth, without oxide scale
5. Good Extending and Bending Ability.
| Product Name | EN10305-1E235 E355 Steel Tube Welded Hydraulic Bright Annealed Steel Tube |
| Material | E215, E235, E255, E355 |
| Delivery Condition | +N (Normalized) |
| Standard | EN10305-4 |
| Application | Hydraulic Cylinder |
| Certificate | TS16949, ISO 9001 |
| HS code | 7304319000 |
| Delivery Time | 45 days |
| Pakcing | Bundles or Woodern Boxes |
| Steel Grade | Chemical Composition | |||||
| Symbol | Material Number |
C Max. |
Si Max. |
Mn Max. |
P Max. |
S Max. |
| E235 | 1.0308 | 0.17 | 0.35 | 1.20 | 0.025 | 0.025 |
| E255 | 1.0408 | 0.21 | 0.35 | 0.40--1.10 | 0.025 | 0.025 |
| E355 | 1.0580 | 0.22 | 0.55 | 1.60 | 0.025 | 0.025 |
| Steel Grade | +C | +LC | +SR | |||||
| Name | No. |
Rm Mpa |
A % |
Rm Mpa |
A % |
Rm Mpa |
ReH Mpa |
A % |
| E235 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 350 | 16 |
| E255 | 1.0408 | 580 | 5 | 520 | 8 | 520 | 375 | 12 |
| E355 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450 | 10 |
| Steel Grade | +A | +N | ||||
| Name | No. |
Rm Mpa |
A % |
Rm Mpa |
ReH Mpa |
A % |
| E235 | 1.0308 | 315 | 25 | 340--480 | 235 | 25 |
| E255 | 1.0408 | 390 | 21 | 440--570 | 255 | 21 |
| E355 | 1.0580 | 450 | 22 | 490--630 | 355 | 22 |
Cold drawn steel tube which offers uniform tolerances, enhanced machinability and increased strength and tolerances compared to hot-rolled products. The cold drawn process increases the tube's physical properties and offers better tolerances and reduced machining allowances over hot finish seamless.
