Zinc Coated ERW Steel Tube with 0.5mm Thickness for Refrigeration Application

Name: Zinc Coated ERW Steel Tube with 0.5mm Thickness for Refrigeration Application
Brand: Jiangsu Hongbao Group Co., Ltd.
SKU: BHG1
Price: 22.00 USD
Availability: InStock

Product Details

Place of Origin: Jiangsu, China

Brand Name: Hongbao

Certification: ISO

Model Number: BHG1

Payment & Shipping Terms

Minimum Order Quantity: 5 ton

Price: Negotiable

Packaging Details: Seaworthy plywooden case packaging

Delivery Time: 15 working days

Payment Terms: L/C,T/T

Supply Ability: 30000MT per year

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                Welded Steel Tubing


Material:	BHG1, SPCC, SPCD-SD, SPCD, SPCE	Standard:	ASTM, GB
Thickness:	0.45-1.5mm	Shape:	Coil
Application:	Refrigeration

Material:	BHG1, SPCC, SPCD-SD, SPCD, SPCE
Standard:	ASTM, GB
Thickness:	0.45-1.5mm
Shape:	Coil
Application:	Refrigeration

Zinc Coated ERW Steel Tube with 0.5mm Thickness for Refrigeration Application

SPCC OD4 WT0.5 Zinc Coated ERW Steel Tube, Low Carbon Tube For Refrigeration

Product Overview

Zinc Coated ERW Steel Tube for refrigeration is manufactured through Electric Resistance Welding (ERW) process and then coated with zinc to prevent rust and corrosion. It is widely used in refrigeration systems due to its excellent durability and resistance to low temperatures.

Key Specifications

Main use: Widely used in evaporators, refrigerators, automobiles and heaters
Features: High intensity, good plasticity, and small resistance
Standard: ASTM A254-94
Materials: Can be altered according to customers' requirements
Type: Zinc coating outer side, Cu coating outer side, Cu coating both sides
Packing: Packed with iron pallet
Grade: Low carbon steel tube
Certification: ISO9001, ROHS

Product Features

Economic
Smooth outer surface
Maintaining inner cleanliness to the max. of 0.1948g/m²
Durability with air-tightness against vibration and impact
Diverse processing available

Mechanical Properties

Tensile Strength: ≥290 MPa
Yield Strength: ≥200 MPa
Elongation: ≥40%
Flaring Test: ≥25%
Or produce according to technical requirements

Material Composition

Type	C	Si	Mn	P	S
Cold Rolled Low Carbon Steel	≤0.08	≤0.03	≤0.30	≤0.030	≤0.030
Cold Rolled Ultra-Low Carbon Steel	≤0.008	≤0.03	≤0.25	≤0.020	≤0.030

Available Sizes

Usual Diameter: 4, 4.2, 4.76, 6, 6.35, 7.8 mm (4-12 mm available in production)

Usual Thickness: 0.5, 0.65, 0.7 mm (0.45-1.5 mm available in production)

Production Capacity

Annual Output: 30,000 MT

Technical Advantages

Surface coated copper or zinc available, time of salt spray testing reach to 240 hours.

O.D (mm)	Thickness (mm)	Unit Weight (g/m)	Work Pressure (kg/m²)
4.00	0.5	43.16	350
4.00	0.7	56.97	350
4.76	0.6	61.56	350
4.76	0.7	70.00	350
6.00	0.7	91.49	350
6.00	1.0	123.31	350
6.35	0.7	97.54	350
8.00	0.7	126.02	250
8.00	1.0	172.63	250
9.52	1.7	152.26	250
9.52	1.0	210.12	250
10.0	1.7	160.55	250
10.0	1.0	221.95	250
12.0	0.7	195.07	250
12.0	1.0	271.28	250
12.7	0.7	207.16	250
12.7	1.0	288.54	250
