Premium High-Ductility Small-Diameter Titanium Alloy Tube

Name: Premium High-Ductility Small-Diameter Titanium Alloy Tube
Brand: Jiangsu Hongbao Group Co., Ltd.
SKU: HB-TI
Price: 22.00 USD
Availability: InStock

Product Details

Place of Origin: Jiangsu, China

Brand Name: Hongbao

Certification: DNV,PED,ISO,TUV,LR

Model Number: HB-TI

Payment & Shipping Terms

Minimum Order Quantity: 200kg

Price: Negotiable

Packaging Details: seaworthy plywooden case packing.

Delivery Time: within 50 days

Payment Terms: D/P, L/C, D/A, L/C, Western Union

Supply Ability: 800MT/YEAR

Get Best Price

Product Details

Product Description

Highlight:

Material::	Gr1,Gr2,Gr3,Gr7,Gr9,Gr12	Certificate::	DNV,PED,ISO,TUV,LR
Thickness::	0.4-10mm	OD::	10-114mm
Length::	100-15000mm	Shape::	Round

Material::	Gr1,Gr2,Gr3,Gr7,Gr9,Gr12
Certificate::	DNV,PED,ISO,TUV,LR
Thickness::	0.4-10mm
OD::	10-114mm
Length::	100-15000mm
Shape::	Round

Premium High-Ductility Small-Diameter Titanium Alloy Tube

Premium High-Ductility Small-Diameter Titanium Alloy Tube

Engineered for precision and performance, our small-diameter titanium alloy tube combines exceptional ductility with the strength of premium titanium alloys.

Key highlights:

1. Superior Ductility: Withstands significant plastic deformation without fracture, ideal for complex forming or dynamic applications.

2. Lightweight & Robust: Titanium alloy core delivers high strength-to-weight ratio, reducing system load while ensuring durability.

3. Small Diameter Precision: Available in tight tolerances (e.g., OD ≤25mm), perfect for compact assemblies in aerospace, medical devices, or precision instruments.

4. Corrosion Resistance: Inherent titanium properties resist harsh chemicals, seawater, and extreme environments.

Ideal for hydraulic systems, surgical implants, and lightweight structural components. Trust in a tube that bends without breaking—engineered to excel where others compromise.

Standard	ASTM B337, ASTM B338, ASTM B861, ASTM B862
Grade	Gr1, Gr2, Gr7, Gr9, Gr12
Dimension	ODWTL (10-114)(0.4-10)(100-15000)mm
Manufacturing method	Cold rolled
Condition	Annealed(M)
Features	Light weight, excellent corrosion resistivity, strongly heat-resistance, high strength.
Inspection	Ultrasonic testing, Hydrostatic testing, Flattening testing, visual surface inspection, Dimensional inspection, tensile properties inspection and Chemical elements analysis.

BASIC TENSION DATE

Grade	Tensile Strength, min		Yield Strengh 0.2% offset Yleld				Elongation in 2in or 50mm Min%
	Ksi	Mpa	Min		Max
	Ksi	Mpa	Ksi	Mpa	Ksi	Mpa
1	35	240	20	138	45	310	24
2	50	345	40	275	65	450	20
7	50	345	40	275	65	450	20
9A	125	860	105	725	/	/	10
9B	90	620	70	483	/	/	15c
12	70	483	50	345	/	/	18c
A. Properties for cold-worked and stress-relieved B. Annealed. C. Solution treated

Chemical Component og Material:
Grade1- Unalloyed titanium.
Grade2- Unalloyed titanium.
Grade7- Unalloyed titanium plus 0.12 to 0.25% palladium.
Grade9- Titanium alloy (3% aluminum, 235% vanadium.
Grade12- Titanium alloy (0.3% molybdenum, 0.8% nickel.

Size Tolerance:

Standard	OD Tolerance	WT Tolerance
ASTM B338	＜25.4mm, ±0.102mm	±10%
	24.4-38.1mm ±0.127mm
	38.1-50.8mm ±0.152mm
	50.8-63.5mm ±0.178mm
	60.3-88.9mm ±0.254mm
ASTM B861	3.2-3.8mm -0.794/+0.397mm	±12.5%
	38-102mm ±0.794mm
	102-203mm 0.794/+1.588mm
